Milont - Model P2020 -Magnetic Angle Sensor
P2020 series non-contact magnetic angle sensor, 0-360° high-precision measurement, measurement accuracy 0.088mm, sensor power supply 5-24V DC, output 0-10V, 4-20MA or RS485 digital signal, can be used with all kinds of collectors, Digital display meter, PLC system or computer use.
Most popular related searches
- Dimensions: straight length: 38mm, body height: 33mm
- Weight<200g
- Maximum speed: 6000RPM
- Spindle load: 20N in axial direction, 20N in longitudinal direction
- Allowable axial movement: ±0.5mm
- Allowable movement in warp direction: ±0.2mm
- Connection form: solid shaft, semi-hollow shaft
- Waterproof rating: IP65
- Cable: Standard 8-core shielded cable 1 meter
- Working temperature:-25 ℃ to + 120 ℃
- Storage temperature:-40 ℃ to + 125 ℃
- Humidity: 90%RH
- Anti-vibration: 10G
- Impact resistance: 50G
- Voltage range: 5-24VDC
- Current: 50MA@12VDC
- Power-on time: 100MS
- Insulation resistance: >1MΩlication fields.
- Various mechanical equipment corner detection, length/height measurement, and replacement of various potentiometers and other application fields.
