Misuratori LC - Model MP Series -Bi-Rotor Positive Displacement (PD) Meters
FromSAMPI S.P.A.
Liquid Controls MP Series Bi-Rotor Positive Displacement (PD) Meters offer the ultimate in measurement accuracy for custody transfer of petroleum and aviation fuels. LC MP-Series meters are well-suited for use in industries requiring precise flow measurement and reliable, extended service life: refined petroleum products, crude oil, LPG, power plant, petrochemicals.
Most popular related searches
positive displacement meter
ASTM a216
flow monitoring
stainless steel plate magnet
flanged pipe
pipe flange
viscosity meter
metal thickness monitoring
- Low pressure drop– the straight-through path and floating rotor design creates a very low pressure drop at maximum flow.
- Sustained accuracy– no metal-to-metal contact inside the measuring chamber means minimal wear and deterioration in accuracy over time, fewer recalibrations and a longer service life.
- Wide viscosity range– LC meters can accurately meter products up to 1000 cP (please consult factory for higher viscosity).
- Compact design– no upstream or downstream pipe lengths are necessary.
- Double case construction– the measuring unit is removable, as a single subassembly, from the outer flanged.
- Low piping vibration– the bi-rotor design produces very low piping vibrations permitting to reach higher flowrates.
Material of Construction (Class 1, 8, 14):
- External housing: Carbon steel ASTM A216 WCB
- External cover: Carbon steel ASTM A216 WCB
- Housing: Cast iron (1, 14), 316 stainless steel (8)
- Bearing plate: Cast iron (1, 14), 316 stainless steel (8)
- Sleeve bearing: Carbon/420 stainless steel (1, 14), Carbon/316 stainless steel (8)
- Rotors: Cast iron (1, 14), 316 stainless steel (8)
- Gear: 420 stainless steel (1, 14), 316 stainless steel (8)
- Internal hardware: Stainless steel
- Seal material: Teflon
- Packing gland: Stainless steel/teflon
