MixRite 1 - Model 2801010CL00 -Dosing Pump
Name: MixRite 1. Product Code: 2801010CL00. Thread Type: BSPT. Thread Size: 3/4″. Material: PP+FG. Color: Blue. Min Injection Per Hour: 0.02 l/h [0.005 gph]. Max Injection Per Hour: 10 l/h [2.64 gph]. ON OFF System: Yes [Manual]. Dosage Rate: 0.1%–1%. Water Pressure: 0.2–8 bar [3 to 116 psi]. Working Pressure: 0.2–8 bar. Chemical Resistance: Standard. Flow Rate Range: 20–1000 l/h [0.09 to 4.4 gpm].
Application
MixRite1 is a water driven proportioning injector for pumping an additive into a water line at a consistent induction rate over varying water pressure and flow rates. Especially compact pump generates high injection accuracy and very low flow rate.
Comments
MixRite`s main advantages are: easy to install, no electricity needed, easy to adjust dosing percentage, replaceable seals, works at very low flow rate, easy to field repair, highly chemical resistant, perfect blending, highly resistant to UV.
Overview
MixRite is a water driven proportioning injector for pumping an additive into a water line at a consistent induction rate over varying water pressure and flow rates.
- Thread Type: BSPT
- Thread Size: 3/4″
- Material: PP+FG
- Color: Blue
- ON OFF System: Yes [Manual]
- Dosage Rate: 0.1%–1%
- Chemical Resistance: Standard
