MixRite 1 - Model 28010220000 -Dosing Pump
Name: MixRite 1. Product Code: 28010220000. Thread Type: BSPT. Thread Size: 3/4″. Color: Grey/Blue. Min Injection Per Hour: 0.04 l/h [0.01 gpm]. Max Injection Per Hour: 2 l/h [0.53 gpm]. ON OFF System: Yes [Manual]. Dosage Rate: 0.2% [Fixed Rate]. Water Pressure: 0.2–8 bar [3 to 116 psi]. Working Pressure: 0.2–8 bar. Chemical Resistance: Standard. Flow Rate Range: 20–1000 l/h [0.09 to 4.4 gpm].
Application
MixRite1 is a water driven proportioning injector for pumping an additive into a water line at a consistent induction rate over varying water pressure and flow rates. Especially compact pump generates high injection accuracy and very low flow rate.
Comments
MixRite`s main advantages are: easy to install, no electricity needed, easy to adjust.
Overview
MixRite is a water driven proportioning injector for pumping an additive into a water line at a consistent induction rate over varying water pressure and flow rates.
- Thread Type: BSPT
- Thread Size: 3/4″
- Color: Grey/Blue
- ON OFF System: Yes [Manual]
- Dosage Rate: 0.2% [Fixed Rate]
- Chemical Resistance: Standard
