SIMATIC - Model Series 270 -Mobile Panel

The Mobile Panels of series 270 combine the advantages of mobile HMI with the power of the 270 performance class. Series 270 Mobile Panels are offered as wired devices with 8 and 10 inch TFT-displays and wireless 8 inch devices with standard or failsafe functionality. All wired devices can be connected to PROFIBUS or PROFINET. The selection of the desired communication bus takes place by selecting the corresponding cable and respective connection box. For this, all cables and connection boxes already released for the Mobile Panel 177 are available. The Mobile Panel 277 8 inch is offered in three variants with optional control elements, while the 10 inch version is always equipped with a STOP pushbutton. The Mobile Panel 277 IWLAN is available with standard functionality in two variants and as a failsafe version also in two variants. The failsafe variant is the first wireless operator interface with integrated safety functionality certified according to SIL 3.
