Model 6 GX series -Submersible Motor

Submersible motor 6” GX seriesof water filled submersible motors with encapsulated (canned) stator completely built in AISI 316 for aggressive/salty water. The motor is supplied pre-filled with a coolant (entirely non-toxic) consisting of a water + propylene glycol mixture with anti-oxidant, lubricating and anti-freeze functions (up to -15 °C). The thrust bearing unit and the radial bearings are lubricated by the liquid inside while a membrane ensures variation of the liquid volume as well as pressure compensation. The electric power cable is connected to the motor by means of a watertight removable connector. A mechanical seal in SIC/SIC together with a special sand-guard ensures operation also in the presence of sandy waters; a temperature sensor can be fitted as optional.
