Model 6603 -Oil Separators

INSTALLATION
The device will be buried. It`s planned to be installed in the presence oh phreatic table or with hydromorphic ground whose level doesn`t exceed the superior generator of the device.In case of vehicles passing or a backfill of over 800 mm above the device, it`s necessary to pour concrete sab, taking support on not moved ground in order that the separator doesn`t withstand the strains. Respect the recommandations on installation instruction on P046. The cover will always remain accessible to allow the maintenance. Vent pipes : see sheet C010.

MAINTENANCE
The cleaning company will drain the device regulary when the silt quantity collected affected 50 % of the device volume.
After each draining, it`s imperative to entirely fill the silt storage with cold water.

TECHNICAL DEFINITION
The silt storage is a device designed to separate and store heavy matter (sand, gravel, silt) contained in raw water before their passage in greases separator or oil separator. When it`s placed upstream to a greases separator it permits to lower the temperature of collected water come from kitchen.

DISTANCE EXTRACTION
Distance extraction DN80 is possible by ordering OD4-BBTN option.The installer has to supply and set up a suction tube in PVC to be linked with the exit of the device and has to place, in border of the street, the fireman join delivered with the option.
