Model DAA-3025A, DAA-2525A - Axial Pump Wobble Plate Direct Drive

From

0

Manifold: Forged brass. Crankcase: Aluminum alloy, die-cast, anodized. Wobble Plate: Aluminum forged. Cast iron(optional). Bearing:  Dual thrust bearing. Plunger: Solid stainless steel, heat treatment. Ceramic coating(optional). Plunger Seals: Germany Parker, U type. Lubrication: Splash type, oil type 15W-40.

Unloader
Integrated with manifold, internal bypass trap type, built with detergent injector

INLET: 3/4inch BSP or NH thread

Outlet: M22 male

  • B34 FLANGE C1
  • B34 FLANGE C2
