Model DC 70, DC 80 and DC FLEX -Mini Cutter System
Used mainly for pipe renovation, where digging them up is not appropriate; under buildings, established outside installations (driveways, gardens etc.) But also downpipes in blocks of flats.
The DC 70, DC 80 and DC FLEX cutters are characterised by:
The machinery is very simply constructed, so the need for repairs is low. For the same reason, everyone can work with the cutting equipment with very little instruction and can service and maintain the machinery.
Powered by air, which minimises damage to the machinery itself (no shaking of the cutters themselves while the milling head is operating). The air function also provides better control of the milling itself when compared with hydraulic operations for example.
The cutter only needs a 300 mm well at unlimited depth to gain access to the pipe.
The cutter operates for 70-150 mm through boreholes of 30° - 45°.
Easy to handle while working, no matter whether the task is 2 or 30 m inside the pipe and regardless of whether the service line is at 9 – 12 – 3 – 6 o’clock.
The cutter can be controlled from the drop hole or from an operator vehicle.
Can also be extended with cutters designed for larger pipe dimensions.
