Model LK-TC series -Mechanically-Driven Diaphragm Metering Pumps

The pump liquid ends are made from high grade materials such as polyvinylidene fluoride (PVDF), carbon fiber reinforced polyvinylidene fluoride (CFRPVDF), ceramic, PTFE, and FKM. These chemical resistant components create pumps ideally suited for pumping strong acids and many aggressive chemicals.

A compact, yet robust, drive mechanism is utilized in the LK series. Oversized bearings a and highly reliable worm gear provide a resilient drive unit. A fully-sealed oil bath lubrication system makes the LK highly durable, even for long-term continuous operation and in outdoor installations.
