Model MH-Series -Humidifiers
Perma Pure MH-Series humidifiers use exclusive Nafion selectively permeable membrane tubing and liquid water to continuously humidify gas streams. These humidifiers operate over a wide range of flow rates, and humidify up to 98%RH using de-ionized water as the humidification source.
Product Features
- Humidify gas streams exclusively in the vapor phase
- Humidify adjustment by varying the water temperature
- Humidity up to 98% RH
- Flow Rates to 20 l/min
- Corrosion Resistant
- Sterile
Principle of Operation
The MH-Series gas humidifiers are tube-in-shell moisture exchangers that allow the transfer of water vapor between a liquid water supply and a gas stream. The water is absorbed into the walls of the Nafion tube and then is transferred as a vapor to a dry gas stream. This transfer is driven by the difference in the partial pressures of the water vapor on opposing sides.
Intelligent Product Numbering System
Perma Pure offers the MD-Series dryer with three sizes of Nafion tubing and in a variety of lengths and connection types. Choose the size based on your flow rate and dryness requirement and build your MD dryer according to the selection guide and the part number
