Model Planet Box 70 -Water Captor

Single wall tank, HORIZONTAL AXIS with containment basin. Model approved and compliant with M. D. 11/22/2017. Made of 1st choice S235JR carbon steel, thickness 3 mm. Complete with: Manhole Ø 400 mm. bolted with oilproof gasket and galvanized bolts having; 3 ” inlet pipe with ring nut and bayonet cap in brass, Atex approved, padlockable; vent pipe with Atex approved flame arrestor terminal in brass; 3″ load limiting valve to 90% approved. indicator mechanical level with float, electrical system in accordance with EC standards with emergency button and key for actuating dispensing and electric sensor for blocking the minimum level pump. bottom drain with safety cap for any periodic cleaning, access steps to the manhole for comfortable and safe access during refueling (starting from 3.000 liters capacity), lifting eyebolts for vacuum handling, canopy fixing predisposition welded to the tank;
