F.lli Savi Di Savi Dario & C Snc products

Single wall tank, HORIZONTAL AXIS with containment basin. Model approved and compliant with M. D. 11/22/2017. Made of 1st choice S235JR carbon steel, thickness 3 mm. Complete with: Manhole Ø 400 mm. bolted with oilproof gasket and galvanized bolts having; 3 ” inlet pipe with ring nut and bayonet cap in brass, Atex approved, padlockable; vent pipe with Atex approved flame arrestor terminal in brass; 3″ load limiting valve to 90% approved. indicator mechanical level with float, electrical system in accordance with EC standards with emergency button and key for actuating dispensing and electric sensor for blocking the minimum level pump. bottom drain with safety cap for any periodic cleaning, access steps to the manhole for comfortable and safe access during refueling (starting from 3.000 liters capacity), lifting eyebolts for vacuum handling, canopy fixing predisposition welded to the tank;

Single wall tank, HORIZONTAL AXIS with containment basin. Model approved and compliant with M. D. 11/22/2017. Made of 1st choice S235JR carbon steel, thickness 3 mm.

Single wall tank, with HORIZONTAL AXIS and containment basin. Model approved and compliant with M. D. 11/22/2017. Made of 1st choice S235JR carbon steel, thickness 3 mm.

TANK APPROVED FOR FUEL TRANSPORT (DIESEL or PETROL) made of carbon steel, mounted inside a protective structure in case of impact and anti-rolling. Complete with upper manhole Ø 300 mm. watertight with 10 mm thick plate and counterflange, galvanized bolts and gasket. Double action safety vent to prevent liquid from escaping in the event of overturning with safety valve and approved vacuum breaker, suction with double flange and shut-off ball valve, balanced lifting eyebolts from above, inlets for trolley forks elevator on all four sides and anchoring holes to the floor.

Transportable metal tank (DIESEL or PETROL) with 110% containment, stackable at full load. Cylindrical tank built in carbon steel, tightly welded, powder coated, after sandblasting treatment, contained in a metal container with the function of containment basin at 110% and with padlockable closure. Lockable lid. Top lifting lugs located in the corner supports. Forklift pockets on each side of the container. Possibility to connect the generator sets even with the cover closed and locked. Drainage pipe to empty completely the external container, provided with safety cap.

TRANSPORTABLE TANK IN POLYETHYLENE TOTAL EXEMPTION ACCORDING TO ADR 1.1.3.1c. STANDARD AND PICK UP VERSION. Complete with: Filling cap, safety valve. Nominal capacity transfer unit 40 l / min 12 Vdc on request 24 Vdc. Manual block dispensing gun and 4 mt. dispensing hose. Inlets for full lifting with forks. Handles for vacuum lifting. Padlockable / lockable top cover. Mechanical level indicator standard on all models over 200 liters (optional for PL 200)

Vertical cylindrical tank for storage use with a capacity of 990 lt. (only on order version 490 lt capacity). Built in compliance with the Ministerial Decree of 28 April 2005 and the Ministerial Decree of 22 October 2007 of the Ministry of the Interior. Suitable for connecting generators or a heating group. Version with activated carbon vent, suitable for storing oil.
