Model RCP Series -End Suction Pumps
Rotech’s RCP series end suction pumps are multi-purpose pumps that boast robust design to give maximum output. It consists of axial suction port, radial discharge port and horizontal shaft. They have the back pull-out design to ease the removal of coupling, motor and impeller without disturbing the entire pump housing. RCP series end suction pumps are non-self-priming single stage centrifugal pumps. These centrifugal pumps are suitable for wide range of applications such as industrial liquid transfer, industrial pressure boosting, water supply, HVAC (heating, ventilation and air-conditioning), and irrigation.
- RCP series pumps are non-self-priming, single stage & close-coupled with a completely fan-cooled standardized motor. Main dimensions of motor are according to IEC & DIN standards.
- These pumps are centrifugal volute pumps having axial suction port, radial discharge port along with a horizontal shaft.
- Dimensions of mechanical shaft seal of RCP pumps are as per EN 12756
- Each pump of this series is dynamically balanced according to ISO 1940 class 6.3.
- Impellers of RCP series pumps are hydraulically balanced with a back pull-out design. This enables removal and dismantling of the motor & impeller without any disturbance to pump housing or pipework. As a result of this design, it is possible even for a single individual to service this pump using a crane.
RCP series pumps are economical OEM pumps. Pumps are available in cast iron bronze fitted construction with enclosed impeller. The pumps close coupled with NEMA face motor.
- City water, Municipality
- Water & waste water
- Irrigation & HVAC
- Apartment Building
- Effluent Treatment
- Cooling Tower, Circulating water & Chillers
- Petrochemical, Refineries & Pharmaceutical
- Capacity - 80 gpm
- Head - 100 ft
- HP - 2 HP
