EDUR - Model Series LUB, CV -Multistage Inline Pumps

SHARE

Multistage inline pumps from EDUR stand out due to their compact and vertical design. They are especially used in applications where high pumping pressures are needed.

Most popular related searches
inline pump
multistage pump
industrial cleaning system
stainless steel pump
clean technology industry
cooling system
sensor-based monitoring
clean technology
industrial cleaning
high-pressure pump

EDUR-multistage inline pumps are applied within water technology, cooling technology, energy technology, industrial cleaning technology and in other industry branches. They are especially used where higher pumping pressures are required for conveying pure or slightly contaminated liquids.

We offer high-quality multistage inline pumps with our CV and ECV series. The stainless steel pumps are manufactured in vertical design. The shaft seal is obtainable as single or double-acting mechanical seal. As required, we deliver customer-specific configurations. Of course, we also provide certificates of all authorized classification societies and necessary test reports.

As all EDUR-pumps, multistage inline pumps stand out due to their efficiency, economy and reliability. Moreover, further product advantages are outlined below:

  • Axial thrust-free, open or load-relieved, closed impellers
  • Compensation of radial forces due to diffuser elements in the ring housing
  • Low NPSH values
  • Excellent control behavior
  • Optimized size of pressure nozzle for low pipe friction losses and velocity head difference
  • Protection against dry running
  • Application in vacuum operation
  • Wide range of connections (flange, clamp, and others)
  • Optional sensor-based operation monitoring
  • Easy installation
  • Easy maintenance

Technical data

  • Flow rate: max. 120 m³/h
  • Head: max. 342 m
  • Permissible operating pressure: up to 35 bar
  • Temperature: -30 °C to +140 °C
      • Viscosity: up to 115 mm²/s
