Mount-Sopris - Model QL40-GR -Natural Gamma Probes
The QL40-GR probe measures the amount of gamma radiation occurring naturally within the formations crossed by a borehole. Gamma rays are produced mainly by isotopes of potassium, thorium, and uranium. The gamma log is widely used in the groundwater and mining industries to identify lithology and perform clay content analyses. The tool is supplied as a stackable sub of the Quick Link (QL) product line or it can be run as a standalone tool. The QL40-GR operates on any standard wireline (mono, 4 or 7 conductor, coaxial).
Most popular related searches
aquifer thickness
downhole probe
mining exploration
gamma ray
groundwater exploration
gamma radiation
borehole
uranium
well water
gamma radiation monitoring
- Bed boundary analysis
- Facies changes
- Coarsening/ Fining Sequences
- Identify Clay Aquitards
- Aquifer Thickness
- Uranium Concentration
Borehole Fluid
- Water
- Mud
- Dry
Casing
- Uncased
- PVC Borehole
- Steel
Centralization
- Required
- Not Necessary
- Versatile, ubiquitous probe which functions with a wide range of applications and borehole conditions.
- Matrix .sub files can be modified to output gamma in API units or %wt U3O8 (percent weight Uranium).
- Mount Sopris manufactures more natural gamma and spectral tools than any other slimline manufacturer in the world today.
- Gamma probes with other scintillation materials and sizes can be custom made for your application.
- QL40GR (Gamma) + QL40ELOG (Resistivity) + QL40MGS (Magnetic Susceptibility): Mining, Exploration
- QL40GR (Gamma) + QL40ELOG (Resistivity) + QL40OBI (Optical Televiewer): Exploration, Bedding Planes, and Fractures in Dry holes
- QL40GR (Gamma) + QL40ELOG (Resistivity) + QL40ABI (Acoustic Televiewer): Exploration, Bedding Planes, and Fractures in Fluid-filled holes
- QL40GR (Gamma) + QL40ELOG (Resistivity) + QL40FTC (Fluid Res, Temp): Hydrogeologist’s Tool, Groundwater exploration and assessment
- QL40GR (Gamma) + QL40DEV (Deviation): Lithology, Borehole location
