Pulsar Measurement - Model IMP Lite -Non-Contacting Ultrasonic Level Measurement
The IMP Lite is part of the IMP non-contacting level sensor range from Pulsar Measurement. It is a lower-cost alternative to the IMP level sensor and is designed to be used wherever you need a reliable, non-contacting indication of level measurement. The IMP Lite is compact and low-profile, when used on battery power for intermittent applications, its high-speed boot up of circa 3 second maximizes battery life.
All IMP level sensors from Pulsar Measurement feature unique digital echo processing software and onboard keypads and displays, giving an instant, accurate, and reliable level measurement reading. The units include an analog output to provide simple and easy integration with existing site control systems to drive a display.
IMP non-contacting level sensors are suitable for tank level measurement, water and wastewater applications, stock control, tank volume conversions, industrial level measurement, and many more!
- Compact, self-contained level measurement
- 2-wire configuration
- RJ11 port
- Up to 10 m (32.8 ft) range available
Spec: Description:
- Dimensions: 175 mm (6.9 in) H x 130 mm (5.1 in) D
- Cable entry: 2 x 16 mm (0.6 in) cable glands, 3.5 mm to 10 mm (0.1 in to 0.4 in) cable diameter
- Mounting:
- IMP3 - 3 m (9.8 ft) version: 1.5 in BSP/NPT
- IMP 6 - 6 m (19.7 ft) version: 1.5 in BSP/NPT
- IMP10 - 10 m (32.8 ft) version: 2 in BSP/NPT
- Suits BSP & NPT, parallel and tapered
- Weight: Approximately 1 kg (2.2 lbs)
- Temperature (Process): -40 °C to 80 °C (-40 °F to 176 °F)
- Temperature (Ambient): -20 °C to 65 °C (-4 °F to 149 °F)
- Input Voltage: 11-30 V, 3.5-22 mA
- Accuracy: ±0.25% or 6 mm (0.2 in); whichever is greater
- Resolution: ±0.1% or 2 mm (0.1 in); whichever is greater
- Option: Description:
- Variants:
- Imp+
- IMP I.S.
- Beam Angle (-3 dB half power):
- IMP3: ‹10° inclusive
- IMP6: ‹10° inclusive
- IMP10: ‹10° inclusive
- Operating Frequency:
- IMP3: 125 kHz
- IMP6: 75 kHz
- IMP10: 41 kHz
- Measurement Range:
- IMP3: 200 mm to 3 m (7.9 in to 10 ft)
- IMP6: 300 mm to 6 m (11.8 in to 19.7 ft)
- IMP10: 300 mm to 10 m (11.8 in to 32.8 ft)
- Software: IMP PC
