Novatech - Model 1234 -Oxygen Sensor

Reasons for using Novatech 1234 sensors

• Usable for Oxygen measurement in many processes
• Adapts to positive and negative pressure process streams
• Suitable for many corrosive situations
• Low maintenance and high accuracy

The Novatech 1234 Oxygen Sensors

• Easy-to-operate, reliable, no regular calibration needed
• Select ancillaries for your application
• Accurate, rapid response, low drift Zirconia Oxygen sensor: 1 ppm to 100%
• Connect to the Novatech 1730 Series Oxygen Analysers, analog input card on a PC, PLC, or DCS

Accuracy and reliability

• The Novatech 1234 Oxygen sensors provide accurate and virtually drift-free measurement for years.

Adapting the Novatech 1234 to your application

The Novatech 1234 sensors are available for Oxygen measurement in a range of applications by using ancillary equipment including:

• Process sampling probes available to suit your application
• Integral electric pump and filter assembly for aspirating samples
• Filters for dry dust, wet dust or hydrocarbons
• Flow meter

The Novatech 1234 sensors are responsive

Accurate readings can be made with sample response times as short as 3 seconds to changes in gas composition for Oxygen.
