NST - Model BH-30-063 -Large Volume Horizontal Bare Water Storage Tanks

Bare horizontal tanks can also be insulated with our topcoat R-16 spray-on insulation which make the tank suitable for outdoor usage.

As per ASME regulations, all HLW hot water storage tanks over 36″ diameter are required to have a manway.  36″ diameter and below, manways are optional.

Protect your investment further by installing our Power Anode system.

• Designed for storage of potable water up to 180° F (82° C).– All tanks are constructed and certified – in accordance with ASME IV, Part HLW for 125 PSI (862 kPa).
• Niles Steel Tank’s Ultonium™ lining– Applied to the interior surface of the steel providing a tough wear resistant lining which minimizes the effects of high temperature hot water.
• Magnesium anode rods– For protection and longer service life.  (optional power anodes available on select sizes)
• One 3/4″ Aquastat NPT fittings– Located for optimal temperature reading.
• 9″ Saddle Height– Standard on all horizontal tanks.  Taller saddles are available and allows for easier access to areas under the tank.
• Lifting Lugs– Standard.
• Red Oxide Primer– Shop primer is standard on all tanks. Top coat insulation and finish coats are also available.
• Five year limited warranty on steel tank– Provides warranty protection against tank failure resulting from defects in materials and workmanship.
• Ten year limited warranty on steel tank (with double glass lining)– provide superior warranty protection against tank failure. Double glass lining is not an inventory item, built upon request.

• Code………………………. ASME Sec IV HLW
• Design Pressure………… 125 psi
• Test Pressure……………. 125 psi
• Interior…………………….. Ultonium Glass Lining
• Exterior……………………. Primed Painted
• Supports………………….. Saddles
• Capacity………………….. 175 Gal./ 193 nominal
• Weight……………………. 365 Lbs.

• Heads…………………… Carbon Steel
• Shell…………………….. Carbon Steel
• Couplings………………. Carbon Steel
• Flanges…………………. N/A
• Pipe……………………… N/A
• Manway…………………. N/A
