Dando - Model MK 1000 - Offshore ...

Dando - Model MK 1000 -Offshore Geotechnical Power Swivels

FromDando Drilling International Ltd,

SHARE

The Dando MK 1000 is fitted with a twin worm and single wheel gear totally enclosed in an oil bath case. This power swivel incorporates a 150mm I.D hollow spindle which is mounted on taper roller bearings and is powered by twin piston motors providing controlled rotation and torque in forward and reverse.

Most popular related searches

tapered roller bearing

geotechnical equipment

mounted bearing

Hydraulic piston and gear motor options available
A choice of different ratio’s to suit your drilling requirements
Can be easily mounted on-board drilling vessels and onshore rigs.
Robust twin wormshaft and single gear wheel arrangement.
Simple to maintain
40 Ton loading capacity
Technical support available to advise of the correct hydraulic system suitable for the speed and torque needed.

Estimated Weight: 630 kg
Gear Oil: 18 litres EP Gear Oil Grade 80/90
Hydraulic Oil: Shell Tellus 46 or equivalent
Maximum Pullback: 40,000 kg
Estimated Shipping Dimensions: 1m x 1m x 0.8m
