Lev-Co - Model MP14 - 1400 CFM - 11-006 -Oil Mist Collector

The system is best suited for capturing applications that include metalworking, cutting, forming, and shop environments across multiple industries.

The unit comes with self-draining filters and has a vertical profile. This unit includes a 2" aluminum mesh pre-filter, 3 Mist-Plus main filters. Mounting angles to hang or surface mount unit, and a 10" bottom inlet only. It features a 2" aluminum mesh pre-filter, a Mist-Plus primary filter, and a 1.5 HP BI blower TEFC motor.

Typically, these units are directly mounted to machines horizontally to capture contaminants and can be suspended from any suitable roof support strut.

Main Options:

• Multiple Filter types and configurations
• Sound Attenuation.
• Preventative maintenance pressure gauges
• Variable Frequency Drives

• Includes filter access door on each side for left or right-hand applications
• Acoustically lined blower cabinet
• Max Door Opening: 19 ft ²
• Ultra-Seal® filter mounting system
• On/Off Switch for 115 Volt Units
• One/Three Phase Motor

Specifications:

• Construction: 18 Gauge welded steel cabinet with powder-coat finish
• Blower Pkg (HP): 1.5 HP
• Noise Level (dBA): 75 dBA
• Electrical: 115/230/1/60, 13.2/6.6 amps
• Nominal Air Flow (CFM): 1350

• Exclusive MistPlus® Containment Management System:Delivers over 95% filtration efficiency; reduces operating costs by extending maintenance cycles and filter life.
• Baked-on Powder Coat Finish:Resists harsh industrial environments.
• Front Access Filter Door:Eases filter access; reduces filter maintenance and changeout time.
• Sloped Drain Pan.Facilitates reclamation of captured oil mist.
• Lever locking Filter Mounting:Eliminates contaminant bypass of filters.
• Small Footprint:Compact cabinet requires minimal floor space; eases machine and wall mounting.
• Continuous Draining:Provides for longer filter life.

Top 5 contaminants/processes/applications:

• Grinding sparks
• CNC Machining
• Lathe Work
• Aerospace Machining
• Cold Heading of Metals

Don`t see your contaminants? Give us a call! 1-888-862-5356 or Click our instant chatbox.

IMPORTANT: For your Health and Safety, make sure to talk to an application engineer before purchasing.

MP14
MP14 industrial air cleaner with a 1.5 Hp TEFC motor 230/1/60 Hz

MP14-2
MP14 industrial air cleaner with a 1.5 Hp TEFC motor 208-230V/3/60 Hz .

MP14-3
MP14 industrial air cleaner with a 1.5 Hp TEFC motor 575-600/3/60 Hz

• Filter Options (when ordering with main unit)
• Replacement Filters
• Sound Attenuation
• Preventative Maintenance Pressure Gauges (when ordering main unit)
• Variable Frequency Drives
• Hose for Oil Mist
• Hose Rings
