PEWE - Model OWS-P -Oil/Water Separator
The unique technology built into each PEWE OWS-P Multi Phase Oil/Water Separator maximizes oil solids removal while minimizing chemistry usage. The chassis and vessel are constructed of AISI 304SS. With the Diamond Perf separation and adjustable ParaLam Weir system the OWS-P Oil/Water Separator operates with complete precision of the optional PEWE Command Control automated panel. A pipe flocculator is available for chemical efficacy enhancement as well. PEWE products and systems are designed in-house and produced under tight quality control. PEWE offers products worldwide to the food, petrochemical, pharma, metal, electronic, and other industries along with the municipal market.
The heart of the separation technology behind the PEWE is the OWS-P® Multi Phase Oil/Water Separator precision engineered Diamond PerfTM separator internal to the unit. Based on physical principles of Stoke’s Law, the design creates the specific conditions for separating the oil particles along the surface of the web matrix and conveying them to the surface collector while the water exits for reuse or discharge.
OWS-P® Multi Phase Oil/Water Separator chassis is very robust for handling heavy oil solids. The all welded AISI 304 stainless steel vessel is standard with 0.125” plate. Custom steel material and thicknesses are available to suit your particular application. Additionally, the OWS-P® can also be ordered with a screw auger conveyor discharge for extra heavy solids and sand loads. Simply let us know your specific requirements.
