OSSI - Model OSSI-010-022 -Wave Gauge Blue for Submersible Self Logging, Self Powered Pressure Sensor
Wave GaugeBlue: OSSI-010-022 The Wave Gauge Blue is a submersible self logging, self powered pressure sensor. It combines a temperature compensated, highly stable, pressure sensor, a Compact Flash Card Data Logger, a rugged waterproof package and 12 C size Alkaline Batteries. See the Data Sheet for complete details and features. (Supplied with 1 battery, 1 Serial Port Adapter and 1 2GB Flash Card).
The OSSI-010-022 Wave Gauge Blue combines a highly stable Pressure Sensor, a Compact Flash Card Data Logger, a rugged waterproof package and 12 or 28 C size Alkaline Batteries. A Low Power Microprocessor records up to 64 GB of data on a Compact Flash Card in an ASCII format and time and date. The Card is easily removed and can be read on any PC using a standard Compact Flash Card Reader. The Logger will collect months of continuous data or years of burst data. Serial Port and Bluetooth connections are provided as a user interface to configure, monitor and upload small test files. Standard pressure ranges are 1 Bar, 3 Bar and 10 Bar. Optional features include: Up to 16 Pressure Sensors Array, Shore Connection and Water Temperature.
- New PC Interface Software to Configure, Monitor and Display Raw & Processed Data.
- New up to 64GB Compact Flash Card Storage
- New Extremely Accurate Real Time Clock
- Maximum ± 2ppm
- New Programmable, RS232, Wireless Bluetooth
- New Optional Features:
- Sensor Array, up to 15 external Pressure Sensors
- Shore Link, RS485
- Water Temperature
- Flush Hastelloy Diaphragm, ABS Plastic Housing
- Power with 12 or 28 C Size Alkaline Batteries
- Months to years of Continuous Operation
- Sample Rate From 2 Hz to 32Hz
- Burst or Continuous Sampling
- Accuracy ± 0.05% FS, -10 ℃ to 65 ℃
- Resolution 0.0033% of Full Scale
- Long Term Stability ± 0.05%FS
