ProMinent - Model DULCOFLEX DFXa -Peristaltic Pump
Feed rate of 10 ml/h to 65 l/h at up to 7 bar back pressure. DULCOFLEX DFXa meters outgassing, viscous, abrasive or shear-sensitive media and is setting new standards in metering. Linear and reproducible metering (± 1 %) is guaranteed with this peristaltic pump under all process conditions. Hose replacement is a very simple process.
A peristaltic pump that brings together the best qualities of ProMinent metering pumps.
The new DULCOFLEX DFXa meters reliably and is simple to operate. This sees the addition of an intelligent peristaltic metering pump to the ProMinent product range. ProMinent is making use of its decades-long experience in the metering pump sector to bring together the best of two worlds. Valve-free metering with the accuracy of a diaphragm metering pump, tapping into all the properties of a peristaltic pump. The applications of this metering pump include very outgassing, high-viscosity, abrasive, shear-sensitive or chemically aggressive fluids.
The liquid end developed and patented by ProMinent makes quick and straightforward hose replacement possible with a unique change concept. The display provides the fitter with precise instructions about the steps to be completed when replacing the hose. The high-performance hoses used guarantee exceptional chemical resistance and a long service life.
The order information required for hose replacement can be found on the pump’s operating menu.
The intuitive user interface with click wheel ensures simple operation of the peristaltic pump.
A brushless direct current motor forms the heart of the DULCOFLEX DFXa. Its ingenious control provides for precise metering and reduced pump capacity with continuous metering up to 10 ml/h. What’s more, the new peristaltic metering pump is IoT-enabled, meaning that it can be fully networked and connected to the DULCONNEX IIoT solution developed by ProMinent.
- Adjustment of the metering rate directly in l/h or ml/h
- Simple hose change
- No problems with very gaseous media or air locks
- Suitable for viscosities of up to 200,000 mPas (with VPT0530/VPT0565)
- Sole contact with media in the hose
- Many different control options, such as using an analogue 0/4-20 mA signal, contact controller, timer or via process control systems
The following list of applications are general examples of generally suitable applications for this product. Please contact your local sales representative to talk about the applicable use of this product in your specific case / environment.
- Drinking water and wastewater treatment
- Food and beverage industry
- Paper industry
- Chemical industry
- All industrial applications, either as a stand-alone unit or integrated in a complete system
- Illuminated 3” LCD and 3-LED display for operating, warning and error messages, visible from all sides
- Adjustable feed rate of between 65 l/ and 10 ml/h
- Connector for 2-stage level switch or continuous level measurement
- 3 additional freely configurable inputs and outputs on one port
- Optional 0/4–20 mA output for remote transmission of actual dosing rate and error messages
- Optional relay module with 1 x switch-over contact, 230 V – 6 A
- Optional relay module with 2 x On, 24 V – 100 mA
- Pump is available as an FDA design
- DULCONNEX-capable
- Connection to process control systems via fieldbus interfaces, such as PROFIBUS®, PROFINET, CANopen or Modbus RTU
- CIP (cleaning in place)-enabled system
- Reverse flow is possible
