Pf – 100 Packaged Bag Filters
Technical Advantages of Cylindrical Pulse Jet Filter: MDSJ AIR Engineering’s Compact Bag Filters, developed to enhance efficiency, reduce maintenance, and minimize size and weight, offer several advantages compared to typical Jet Pulse Bag Filters. The most notable feature is their compact yet robust and modular design, which provides increased cleaning efficiency with reduced size and weight for ease of transportation and installation. Standard Compact Filters are equipped with insulation on the side walls and top section to maintain a consistent bag temperature. As a result, they offer a smaller footprint, larger filter area, and fewer moving parts compared to traditional Pulse Jet Bag Filters, leading to lower maintenance and operating costs.
MDSJ AIR Engineering’s Compact Bag Filters are offered in combination with polyester or mesh bags. They are used for discharge points on silos, conveyor belt spillages, and point dust suppression. They can be produced with or without a complete fan system, with capacities up to 32m2. They are also known for their space-saving cleaning unit. Cleaning is performed during operation for production process and product quality control. Low pressure drop is maintained throughout the filtration process.
- Minimum required ventilation space due to pressure shock resistance of 2 bar/g
- Integrated detonation router
- Twin explosion ventilation concept
- Vertical explosion vent
- Ideal discharge of recoil forces.
- Aluminum venturis
- Stainless steel bag clamps
- 1/8″ 10 wire carbon steel smooth retainer
- Compact timer assembly
- Manometer or Magnetic gauge parts ready for installation
- Primed carbon steel surfaces
- Solenoid valve and timer housings
