PfaudlerModel Type rH -rH Redox Sensor

SHARE

The rH sensor type accurately measures the redox value in applications where conventional probes are unstable and feature a short service life. The Pfaudler Heavy-Duty Design allows it to be installed in-line directly in the product flow. The wear-resistant, smooth glass-lined layer uses the product flow to keep the surface of the sensor clean while resisting any potential product build-up that may occur.

Most popular related searches

The redox potential is measured between a rhodium electrode embedded in the enamel and a pH enamel reference electrode. The magnitude of the potential occurring at the reference electrode depends on the pH value of the product. Thus, a redox voltage is obtained which is not dependent on the pH value.

The rH probes are available in rod design with different lengths.
