Biotal - Model 200 -Plan of Water Treatment Plant
BIOTAL - 200 includes four separately working stations of a capacity 50m3/24-hour-period each, which allow the technical maintenance of Biotal Plant without switching off the entire system, as well as an optimization of working conditions from the point of view of electric consumption.
Most popular related searches
water treatment plant
water treatment
water disinfection
water tank cleaning
sewage water
workstation
water purification
tank cleaning
water tank
SBR reactor
Plan of Water Treatment Plant “ВIOТАL” for deep biological purification of waste waters: capacity 200 m3.
1-2 - reactor SBR 1, 2; 3 - reactor SBR 3; 4 - accumulator - regulator for purification waste water (tank for clean water) V=25 mі; 5 - aerobic stabilizer (tank for unnecessary sediment) V=2x25=50 mі ; 6 - treated waste water disinfecting (by request); 7 - air-compressors ; 8 - buffer tank for waste water in case of blackout V=50 mі ; 9 - outgoing biological clean and disinfect waste water ; 10 -stainless steel grid for large wastes ; 11 - ventilation; 12 - pump for supply sewage water in SBR 1,2 ; 13 - panel with collectors; 14- inflow of waste water ; 15 -sediment water ; 16 - aerators; 17- sediment pump ( tank for clean water); 18 - air-compressor seating;
