PSG All-Flo - Model A100 -Plastic Diaphragm Pump

Air Inlet: 1/4" FNPT. Liquid Inlet: 1". Liquid Discharge: 1". Connection Type: FNPT/FBSPT (Threaded),: ANSI/DIN (Flanged). Max Suction Lift Capability: 15 ft-H2O (4.6 m-H2O) Dry,: 26 ft-H2O (7.9 m-H2O) Wet. Max Flow Rate: 41 gpm (155.8 lpm). Max Pressure: 120 psi (8.2 bar). Max Diameter Solids: 1/4" (6.4 mm). Displacement Per Stroke: 0.08 gal (0.31).
