Plastometer - Model PF-12 -Automatic Hammering System for Organic Samples by High Temperature Resistance Furnace

Automatic hammering (per ASTM D-2639-08, ISO 10329 ) system for sample preparation is included.

Most popular related searches

Automatic hammering (per ASTM D-2639-08, ISO 10329 ) system for sample preparation is included
Automatic evaluation of the final results form 2 or 3 tests according the standard requirements ASTM D-2639-08, ISO 10329
Build – in exhaust device
The temperature measurement failure detection
Cooling of the furnace by the fan
Automatic assessment of each test and the overall result
Automatic creation of * csv files for statistical analysis
The PF-12 plastometer is intended for measuring plasticity properties of black coal heated under the conditions defined by the ASTM D 2639 – 08 and ISO 10329 standard. The outcomes of the test are plastometric indicators of the coal.
The PF-12 plastometer is a fully automatic, compact, single-furnace instrument. A single furnace with molten solder bath is equipped by sophisticated control system of heating range, heating rate to ensure the required accuracy level to meet the requirements of 6.3 of ASTM D-2639-08, ISO 10329.
For quick cooling, the furnace has a built-in fan (allowing another test to be started shortly afterwards).

Features
