Insulation - Model CM 1500 - Portable ...

Insulation - Model CM 1500 -Portable Attic Blower

FromInsulation Machines

SHARE

The CM-1500 gives impressive production rates versus cost in the insulation machine industry. If you want mobility with low power requirements and high production, then this is for you. In-fact, it will take you closer to higher production of large machine capabilities. Insulation was never been so easy but this gives you freedom to cover your quick production needs.

Most popular related searches

slide gate control

electrical safety

The many options (blowers, input power, wheel package), offer choices to the small contractor that require versatility, production, and low maintenance in a high endurance machine. (scalping augers /shredder) A Great Choice for the Weatherization Contractor.

For faster access to airlock it has quick release hopper with easy handling and transport.
To better control of your fiber it adds slide-gate controller
For long lasting finishes with corrosion resistance it uses high quality powder coating.
Manual thermal overloading protection.
Quick release auger provides easy access to airlock seal replacement and service.
Slide-gate control provides precise control of fiber.
Dual scalping augers /shredders increase fiber conditioning while providing consistent flow.
#40 nickel plated chain and hardened sprockets, are rugged, and corrosion resistant.
One or two integrally mounted 2 or 3-stage blowers w/check valve and filter protection.
Modular design with see-thru access panel for quick troubleshooting and maintenance.
100 ft. dual function (3-position) remote cord w/cord hanger, offers control and convenience.

Electrical

It has extensive safety features. sill switch and manual override controls promote increasing operator safety and quick hazard response.
For accessory devices it includes duplex auxiliary outlets.
Deluxe voltmeter for quick electrical diagnostics and low voltage protection of motors.

Weight

1-Blower: 265 lbs
2-Blower: 285 lbs

Airlock

Extruded steel
10″ long x 14″ diameter
3″ output for blowing hose
Quick release auger for access to airlock seals

Power

Single input, 15/20 amp 120 volt single blower
Double input, 15 amp 120 volt double blower (8 amp & 12 amp 230 volt / 50hz, for export)

Dimensions

24 W x 38 L x 57 H

Blowers

8.4 dia., 140 CFM, 13 amp. Magnum super blower provides higher blower output capacity with double the service life
One,3-stage (120volt 12.5amp.)
Two,3-stage (120volt 12.5amp.)

Capacity

15cu/ft. (3 bags of cellulose; 1/2 bag of fiberglass)

Material: Different materials may produce varying results.
Lbs p/hour: Based on industry-wide standards of 100` hose with 12` rise
Bags p/hr: Standard bags (lbs noted by material)
Sq Ft p/hour: Based on R-19 depth
