Metrohm i-Raman - Model Prime - 1064 - BWT-840001082 -Portable Raman Spectrometer
FromMetrohm AG
The i-Raman® Prime is a low-noise, high-throughput, and completely integrated Raman system with an embedded tablet computer and a fiber-optic scanning probe which Raman supplies in research quality, including real-time quantification and identification functions. The system with high throughput offers an outstanding signal-noise ratio, so that even the smallest Raman signal can be measured and the finest sample difference can be detected. The i-Raman Prime 1064 features a unique combination of wide spectral coverage and high resolution, enabling measurements from 100 cm-1 to 2,500 cm-1 in a compact, mobile design.
Most popular related searches
portable raman spectrometer
raman
raman system
raman spectroscopy
raman spectroscopy system
fiber optic probe
portable raman
raman spectrometer
spectroscopy raman
fiber optic raman probe
- Laser Power: 340 mW, nominal
- Laser Wavelength (nm): 1064
- Laser Power Control: 0 to 100% (adjustable at 1% increments)
- Range: 100 - 2500 cm-1
- Resolution: <10.0 cm-1@ 1296 nm
- Detector Type: High Sensitivity InGaAs Array
- CCD Temperature (°C): -20
- Integration time: 0.2 ms – 5 min
- Computer interface: USB 2.0
- Trigger: Yes (Compatible with B&W Tek Probes)
- DC Power Adapter Input: 100-240 VAC 50/60Hz.
- DC Power Adapter Output: 12V DC @ 6.6 Amps
- Battery: Optional
- Dimensions: 15.7 in x 10.2 in x 9.8 in (40 cm x 26 cm x 25 cm)
- Weight: ~19.5lbs (~8.8kg)
- Operating Temperature (°C): 0 - 35
- Humidity: 10% - 85%, non condensing
