LUMINOR - Model Blackcomb 6.0 -Residential UV Water Disinfection
For the ultimate in residential UV disinfection, LUMINOR`s Blackcomb6.0 line should be your choice. Incorporating a true 254nm discrete UV monitor, this Blackcomb series offers the ultimate in continuous monitoring for 24 hour peace-of-mind. Using Teflon technology for reduced fouling, these sensors allow for the addition of a solenoid shut-off valve and a 4-20mA output allowing for remote monitoring or data logging. A colour user interface allows for easy visual identification of UV intensity, remaining lamp life and any error or fault codes as well as a monitoring of a full system diagnostic on start-up. The system even incorporates QR codes to access lamp change information and videos via web access. The controller is a constant current electronic power source and is housed in a splash-proof case that comes standard with a “future-proof” expandability port for future upgrades or options.
Rugged 304 stainless steel, single-end reactors allow for lamp change without the need to drain the reactor chamber. Reliable, industry proven, high quality low pressure (LP) coated UV lamps are used offering a consistent output over their 9,000 hour life. Flow rates of 20, 40 & 80 lpm (6, 10 & 20 gpm), in both 120V or 230V applications, are offered in the Blackcomb6.0 series of products.
If you are unsure of the microbiological quality of your source water or if you are looking for additional security from your municipal water source, then LUMINOR has the solution in the BLACKCOMB6.0 series of residential UV systems.
UV technology is proven to control microbiological (bacteria & virus) issues in water including E.coli, Cryptosporidium and Giardia lamblia.
BLACKCOMB6.0 provides the ultimate in UV protection for your home with the inclusion of a true 254nm Teflon® based UV sensor that continuously monitors the performance of the UV system and displaying the output via a colour screen. In addition to UV output, diagnostics, system status, warnings, even QR codes are included. With the integral expandibility port, the addition of a 4-20mA output or a solenoid valve is a simple plug-and-play option!
- True 254nm Teflon® based UV sensor continuously measures UV output and visually displays output via the controller
- Colour user interface with full diagnostics and warnings including QR codes
- “Future-proof” expandibility port for future upgrades and options
- Single ended, 304 stainless steel reactors
- Designed & manufactured to ASME pressure vessel standards
- Flow rates stated at 95% UVT at a dose of 30mJ/cm2
- User friendly bayonet style lamp connector (quick ¼ turn removal with no extra tools needed)
- True gland seal retaining nut with positive stop
- Reliable, industry proven low pressure (LP) coated UV lamps with ceramic bases for durability and a 9000 hour life (1 year)
- Constant current electronic controller (one controller for all systems) in a splash-proof case
