Cirrus Research plc - Revo Whole-Body Vibration Meter

The Revo Whole-Body Vibration Meter is a powerful meter that gives you all of the data you need to complete your vibration assessments while complying with the Control of Vibration at Work Regulations 2005 and ISO 2631.

• Whole Body vibration measurements in accordance with ISO 2631
• Four independent measuring channels with IEPE inputs and TEDS support
• 3-channel integrated frequency analysis (FFT) for the detection of main frequencies
• Stores up to 10,000 measurements and up to 1,000 FFT Measurements
• Colour screen display of running and interval measurement values
• USB interface for quick download of your data
• Includes a free reporting package to analyse your data

The Revo whole-body vibration meter gives you the Vector Sum m/s2 (of the triaxial seated or standing vibration measurement consisting of X, Y and Z), and the m/s2 A(8) vibration exposure over your average over a working day.

The Control of Vibration at Work Regulations introduced an:

• Exposure action value (EAV) of 0.5 m/s2 A(8) this is the level that employers should introduce technical and organisational measures to reduce their employees exposure
• Exposure limit value (ELV) of 1.15 m/s2 A(8) this is the maximum level that should not be exceeded.
