Rpmtech - Model MHP Series -Electro-Hydraulic Actuator for Multi-Turn Valves
RPMTECH`s MHP Multi-Turn Series products are Electro-Hydraulic Actuators built for multi-turn valves (Gate Valves, Globe Valves, etc.). The MHP Multi-Turn Series is a compact, all-in-one solution that is capable of advanced control modes for maximum versatility.
Most popular related searches
hydraulic actuator
manual hand pump
gate valve
water proofing
valve actuator
hydraulic cylinder
globe valve
actuated valve
MHP Multi-Turn Series
Electro-Hydraulic Actuator for Multi-Turn Valves
- Single Power-pack
- Graphic LCD
- Highly Configurable Parameter Settings
- Various Types of Installation (ex. Separate Installation)
Torque Range (Contact for higher torque)
90 Nm ~ 420 Nm
- Compact, All-in-one Electro-Hydraulic Actuator
- Does not require gearbox: direct power delivery (high efficiency)
- Modular design (easy maintenance)
- Equipped with patented manual hand pump
- Various installation types (able to install actuator and hydraulic cylinder separately for safety and ease of use)
- Limit settings and parameter settings are easily accessible
- Self-diagnosis capabilities and password lock for added security
- Various advanced control modes (refer below to Control Modes)
- Audible and visible alarm during abnormality
- Supports various communication platforms (AIO/DIO, Profibus, etc.)
- Power: Single-Phase AC 110~220V (50/60 Hz) or Three-Phase AC 380~460V (50/60Hz)
- Enclosure Rating: IP68 Water-proof or Exd II B T4 Explosion-proof
- Motor Specs: Bidirectional 0.6kW BLDC Motor (DHP Series: 1.2 kW)
- Torque Range: 90 Nm ~ 420 Nm (Contact for higher torque)
- Minimum Open/Close Time by torque:
