The Si-61 is a piston pump with built-in tank (0,37l) designed to remove acidic condensates from gas condensing boilers up to 50 kW. The Sauermann® technology inside the pump enables small particle removal. Together with the innovative float, this technology makes the pump fully reliable in a condensing boiler environment. Very small, the Si-61 can always be easily installed.

Most popular related searches

condensate pump

centrifugal pumping

condensate pumping

centrifugal pump

anti-vibration mount

integrity monitoring

boiler condensate

Higher Lift than a centrifugal pump
Easy to install
Resistant to pollution

Max flow rate 5 gph10 l/h
Max discharge head 20 ft, 6 m
Max pressure 8 m
Insulation class Double insulation
Mains supply 230V ~ 50/60Hz ~ 10 W
Operation conditions 100%
Protection IPX4
Tank volume 0.37 L
Master pack quantity 5
Safety switch NC 4 A resistive – 250V
Detection Integrated, magnet

1 Si-61 piston pump
1 Integrated float detection unit
1 1.5m lockable plug-in power cable: 2 power wires, 2 safety switch wires
1 Inlet rubber adapter int.15-20-24-32-40mm
1 Anti vibration wall-mount bracket with rubber dampers
1 5m tubing int. 6mm
1 Drain Safe Device
1 Self-sealing discharge fitting
1 4 double wire spring clips
1 2 screws + 2 plugs
