Inox - Scraped Surface Blades Horizontal Agitator
This type of agitator provides an excellent method of lifting and folding product for uniform mixing and even cooking.
Agitator scraper blades contact the heated surfaces of the bowl and effectively eliminate product `burn-on` during heating and cooking.
Our scraper blade arrangement has been developed over many years of industry experience. Material used is engineered plastic detectable by metal detection equipment which can also withstand the high temperatures of steam jacketed vessels and is food grade compliant.
Our design is cleanable by CIP, and blades can be easily serviced
Design For CIP Cleanability
INOX processing systems are completely CIP (clean-in-place) cleanable, including vacuum and condensor pipe loops.
- INOX closed process kettles and steam jacketed kettles are available in sizes from 50L up to 3,000L.
- Designed with options to suit any application.
- Tilting operation is available for unloading into hoppers.
- Internal shell pressures: 430kPa (155 deg C)
- External jacket pressure: 620 kPa (166 deg C)
- Agitators are available as vertical or horizontal.
Sizes & Specifications Available
- INOX process retorts are available in many custom sizes.
- Standard diameters are 1,255mm and 1,400mm.
- Designed with options to suit any particular application.
- Tilting operation is available for unloading into hoppers.
- Steam jacketed kettles are available in sizes from 50L up to 3,000L.
- Internal shell pressures: 430kPa (155 deg C)
- External jacket pressure: 620 kPa (166 deg C)
- Agitators are available as vertical or horizontal.
