Auger-Torque - Model 21T to 50T -Screw Pile Torque Heads

Auger Torque’s Earth Drills are built to the most exacting standards using only high quality materials and the latest manufacturing techniques available.

150mm Hex Shaft

The driveshaft is crucial for reliability and it goes without saying that the bigger the better applies here. A shaft is always stronger when machined as a hex and the 150mm diameter is the largest in the industry, especially when looking at compatibility on machine as small as 21T.

Axial Piston Motor
Axial Piston Motors allow us to run a single speed motor. By using an axial piston motor with our drive we can have a high speed motor but still achieve high torques through the gearbox multiplication. At maximum ?ow we achieve 15 rpm.

Single Piece Non-Dislodgement Shaft

As standard with all of our auger & screw pile drives, our patented single-piece non-dislodgement shaft is of course a standard feature. We are so confident in this must have safety feature that we are covering it with a lifetime warranty.

Epicyclic gearbox
Torque is amplified by using the unique Auger Torque planetary gearbox. This system allows the motors output torque to be multiplied with extreme efficiency as well as ensuring the durability and reliability you need.

• Up to 100,069 Nm of Torque
• Up to 15 rpm rotational speed
• Massive 150mm Hex Shaft
• Large main shaft bearings
• Non-Dislodgement Shaft
• Life time non-dislodgement guarantee
• Low-weight at just over 1T
• Single-piece driveshaft
• Compatible with AT Alignment Monitors
• Covered by Auger Torque’s industry leading warranty

• Large diameter & deep auger drilling
• Hard Rock Auger drilling
• Core barrel drilling
• Pole and mast installations
• Foundation piles
• Large diameter screw pile installations
• Rail applications
• Exploration & research
• Compatible with excavators from 21T onwards allowing for low impact and reasonably tight access application where typically larger machines would have to be used.
