Second Sight - Model MS - Gas Detection Camera
Designed for early warning and real time visualization of dangerous gases, the Second Sight® MS is the perfect solution for critical area surveillance and protection against chemical threats (Chemical Warfare Agents, Toxic Industrial Compounds). The Second Sight® MS detects, identifies and visualizes a cloud of dangerous gas in real time at a distance up to 5km, for a night and day surveillance.
- More about this product — External link
-
Most popular related searches
The Second Sight MS is a passive, long range chemi...
The Second Sight MS is a passive, long range chemical and toxic gas clouds detector that is ideally suited to military and civil security operations due to its compact, lightweight and modular design.
It has been designed for early warning and real time visualization of suspicious gas clouds. With its infrared sensor, it shows as an overlay the localization of dangerous gases such as toxic industrial gases or chemical warfare agents (nerve gases or vesicants).
Second Sight can identify the family of the gas and measure its path length concentration.
With its unique gas X feature, it also detects gases that are not in the database, which is ideal when gases are impure, mixed or unknown. With a night and day infrared imaging capability and the largest Field of View (FOV) of any stand-off detector in the market, this tried and tested system is a clear favorite with military forces, law enforcement agencies and emergency responders around the world.
Datasheet
Technology:
- Infrared spectral imaging
Catalogue number:
- 003075-003
Detection range and Field of View:
- Detection up to 1000m with 60×48° FOV
- Detection up to 2000m with 30×24° FOV
- Detection up to 5000m with 12×9° FOV
Detected gas:
- Gas X: detect all gas clouds that absorb in band III infrared
- Most CWA and TIC
Time to alarm:
- in approx. 10 seconds
Scan mode vertical angle:
- 180° x 15° in less than 3 minutes
Dimensions & Weight:
- Head camera: 35 x 19 x 24 cm 5.2 kg
- Processing unit: 26 x 19 x 15 cm 5 kg
Temperature:
- – 20°C to 45°C (operation)
- – 20°C to 70°C (storage)
Ruggedized:
- Mil Std 810-G
Ingress protection:
- IP65
Downloads related to this product
Videos related to this product
-
Second Sight MS, passive standoff gas cloud detector
Second Sight MS is a passive standoff gas cloud detector for real-time detection, localization and identification of chemical threats.
