AerserviceModel LAB -Self-Supporting Arm for Labs and Non-Heavy Works

SHARE

The LAB self-supporting extraction arm is made of light aluminium alloy and it has been designed exclusively for the extraction of fumes or micro-particles generated by non-heavy work processes, with medium-low pollutant concentrations. It can be installed on worktops or walls and it can be completed with different types of nozzles depending on the application. It is characterized by exceptional manoeuvrability and versatility thanks to its light and functional structure. The totally smooth contact surfaces prevent accumulation of microparticles. Not to be used for dust or liquids.

Most popular related searches

AVAILABLE MODELS

  • LAB Ø 50 mm - L. 1 m

ACCESSORIES

  • Painted steel bracket for worktop or wall-fitting
  • Standard hood - in aluminium, L. 180 mm
  • Conical hood - in painted aluminium alloy, Ø 160 mm
  • Rectangular hood - in plexiglas, L. 100/ 200/ 300 mm

Structure

LAB is a self-supporting extraction arm in light aluminium alloy, which combines lightness and resistance to pollutants. The ABS structure with external regulation allow an easy set up. The arm is provided with support brackets in painted steel for fitting to the wall or on the worktop, with couplings designed for flexible hoses. It is suitable for centralized ventilation systems as well as for single extraction stations.
