Shaftless Screw Conveyor
Screw conveyor, commonly known as auger, is a continuous conveying device. It is suitable for conveying powdery, granular and small blocks in short horizontal or vertical directions. It is not suitable for conveying materials that are easy to deteriorate, sticky and easy to agglomerate. It will adhere to the spiral during transport, and will not move forward with the rotation, or form a blockage at the hanging position, so that the screw conveyor can not work normally. The ambient temperature is usually -20 to 50 °C.
- Pipe screw conveyor
- Application: 0-90 degree delivery is possible. The material characteristics are high and should not be cleaned up.
- 2.U-shaped groove screw conveyor
- Strong anti-winding, no interference from the central axis;
- If the belt is belt-shaped and easy to entangle the material, it has a strong superiority.
- The tank body is provided with a lining
The shaftless screw conveyor is a kind of equipment that rotates and transports materials without a central shaft by a spiral body, and has good environmental protection performance. The fully enclosed conveying and easy-to-clean spiral surface ensure environmental sanitation and the materials to be transported from contamination and leakage. Large torque and low energy consumption. Since the screw has no shaft, the material is not easy to be blocked, and the discharge port is not blocked, so that the machine can be operated at a lower speed, and the transmission is smooth and the energy consumption is reduced.
