Chemtrol - Model BT110 -Single Blowdown Boiler Controller

• Conductivity or TDS control with choice of bleed programs.
• High temperature monitoring.
• Automatic calculation of the Langelier Saturation Index (LSI) for water balance.
• Five separate feed programs for up to three (3) chemical additives such as inhibitors, biocides, dispersants, etc.
  • Manual
  • Cycle Timer
  • Auto bleed-and-feed
  • Auto bleed-then-feed
  • Percent of flow
  • Daily schedule
  • Two week schedule
• “Booster” chemical feed program to schedule a delayed one-time feed event
• Low chemical level alarm (based on accumulated run time of  feed outlet)
• Dynamic probe testing with sensor failure warning for pH.
• Differential signal amplification for added stability.
• Choice of 1, 2 or 3-point calibration.
• Automatic data logging.

Options

• OPTION pH: pH monitoring with automatic acid/based control ( model BT110 )
• OPTION COMM: Full duplex remote computer operation, Web access communications

The CHEMTROL® BT110 controller operates like a computer with an LCD screen display and direct access to all menus and submenus. The front panel keypad is used to move up and down each menu and enter or exit the submenus. All operating functions can be easily modified from the keypad, including sensor calibration, control setpoints, alarm levels and the different feed programs.
