Integrated Optics MatchBox - Model 405 nm -Single-Mode Fiber-Coupled Laser Diode
Single-mode fiber-coupled 405 nm laser diode in the compact and robust MatchBox platform. Proprietary fiber coupling technology offers alignment-free operation throughout the lifetime of the laser. Single-mode fiber ensures ideal beam quality and focusability, thus making this laser the best choice for high-resolution fluorescence imaging or 3D lithography applications. Proprietary fiber coupling technology ensures good power stability and excellent fiber-coupling efficiency.
A core-less end-cap is included for fiber tip protection against optical damage and degradation due to optical radiation.
By default, this type of laser is built with FC/PC connector, but other fiber terminations are available upon request. Details about non-standard connector and the fiber used with it should be discussed with the Integrated Optics sales team.
Laser Diffraction Particle Analysis
None
Confocal Microscopy
Confocal microscopy is a powerful imaging technique used in biological and materials science research. By employing point illumination and a spatial pinhole, confocal microscopy eliminates out-of-focus light, resulting in sharper, high-resolution images. This method enables three-dimensional imaging of specimens with exceptional optical sectioning, making it valuable for studying biological structures and dynamic processes at the cellular and subcellular levels.
Food sorting
None
Flow Diagnostics
None
