Romind - Single-Phase Short-Circuiting Device for Round Section Bars
Application: from the ground, by hanging the phase clamp on the round section conductor, followed by the tightening of the clamp driving screw. Classic / automatic phase clamps must be handled using an insulating stick according to the voltage of the installation, provided with “RO bayonet’’ coupling system.
Constructive phase clamps:
- Classic Universal Clamp (CCU)
- Automatic clamp (CA)
- Lightweight classic universal transversal clamp (CCTU/E)*
* The short-circuiting device equiped with CCTU clamp cannot be used on fixed ”T” coupling
Components:
- Phase clamp – 1 piece
- Earthing cable – 1 piece
- Earthing clamp – 1 piece
Packing: waterproof bag.
Other equipment to be used in conjunction:
– connecting insulating stick type PMU 110-2 B/ba / PMU 220-2 B/ba / PMU 400-3 B/ba
Tips: considering the inclined position from the ground and at the height of conductors in transformer stations, we firmly recommend the permanent mounting on such conductors of ‘’T’’ fixed couplings or other round cross-section parts to provide ergonomic conditions for the mounting of the phase clamp of the short-circuting device.
- Phase clamp – 1 piece
- Earthing cable – 1 piece
- Manual earthing clamp – 1 piece
