Power-Lifts - Model EL -Single Scissor Lift Tables

Over 40 different types - Stroke approx. 0.62 x platform length - Upto 15t payload - Multi purpose use - Strong, reliable design.

Most popular related searches

Flat or tear drop pattern deck top, The top roll over edges of our scissor lifts are are square (not radius) for greater strength, smoother load transfer and flush mounting of handrail, conveyors etc.
A perimeter safety trip frame is fitted to the undersides of the platform to prevent further lowering should an obstruction be encountered. For added safety, operator reset is standard.
The scissor arms for lift tables up to 3 metres in length are usually profiled, solid steel. For larger lifts, steel hollow section is used to provide greater stability. A substantial torsion tube is fitted between the armsets to help ensure good synchronisation and stability even when the scissor lifts are eccentrically loaded.
Bearing bushes - Pre-Lubricated, replaceable type bearing bushes are standard features
The 1.400 rpm power packs are selected for their exceptional reliability and low noise (
Steel swivel stops or posts are provided to mechanically support the lift in a raised or semi-raised position to allow access for maintenance purposes.
The steel arm roller bearings are replaceable.
Cylinder Tubes - Our own, high quality cylinder tubes are made from Fe510 steel
