Sodistra - Air Hanling Unit

The Sodistra composite material and manufacturing method enables you to have an AHU that is screw- and welding-free, and to obtain a monocoque structure without thermal bridges. The advantages of AHUS lie in the material used for its manufacture and the way it is assembled, which gives it a unique hygienic design. It is a watertight monocoque housing like the hull of a boat.

• Ultra-cleanliness
• Corrosion resistance
• No condensation
• Isothermal product
• Perfect impermeability
• Light structure

Product composition:

Composite panel in a wall


2 reinforced polyester faces

• Resin for protection
• Gelcoat for the finish
• Glass fibre for resistance
• The interior and exterior surfaces are completely smooth : good hygiene

Insulating foam

• Thickness from 55 to 200 mm

Resists temperatures from -35 to +45°

Raised floor

2 reinforced polyester faces

• Resin for protection
• Gelcoat for the finish
• Glass fibre for resistance

Insulating foam

• Thickness from 55 to 200 mm

Safety reinforcement

Slope and reverse slope

• Facilitates maintenance and cleaning: run-off ofcondensates at a single point

Resists temperatures from -35 to +45°

3 assembly finishes

Polyester bridging lamination

Polyester profile assembly

Mixed assembly

• polyester profiles in walls and polyester bridging lamination for the wall/floor connections
