Solinst - Model 101B -Solid Entry-Level Instrument for Level Measurement
The model 101B is the entry-level product for water level measurement at groundwater measuring points. The level meter is qualitatively on the same level as the other models, it has been reduced to the most important functions. The groundwater level as well as the position of the probe can be read off the durable plastic measuring tape. The measuring tape is available in lengths of up to 100m, with a matching drum. Furthermore, the tape measure offers laser marking with centimetre graduation.
The Solinst Model 101B Water Level Meter is designed to be an economical and basic, yet durable instrument to measure groundwater levels. It is ideal for measuring depth to water in wells, boreholes, standpipes, and tanks.
The Model 101B Water Level Meter uses a solid stainless steel probe, connected to durable polyethylene flat tape. A standard 9 volt battery, housed inside the reel hub, powers the Water Level Meter. The electronics are coated for water resistance. When the probe enters water, the electrical circuit is completed, sending a signal back to the reel where a light and clearly audible buzzer are activated. The water level is then determined by taking a reading directly from the tape at the top of the well casing or borehole.
Long-life stainless steel measuring probe
The probe is made of stainless steel and is waterproof. The measuring point is placed near the tip of the probe to minimise water displacement during the measuring process. The connection between the measuring tape and the probe is designed for easy replacement, so that the probe can be changed individually should this become necessary.
- Measuring tape length up to 100m
- Stainless steel measuring probe
- Buzzer and LED
- Durable plastic tape measure
- Measuring operation with standard 9V battery
- Rugged drum with ergonomic handle and brake
- Measuring the level at groundwater measuring points
- Measure tank contents
- Level measurement in wells
