Salzgitter - Model SB22 -Soot Blowers for Industrial Applications
Salzgitter Kesselservice offers a comprehensive range of soot blowers designed for the most demanding conditions found in waste incineration plants and biomass power stations. Utilizing over 20 years of experience in soot blower service and optimization, these systems are constructed to handle extreme environments and are entirely manufactured in Salzgitter, Germany, ensuring both high quality and rapid delivery. Depending on the cleaning task and availability, steam, compressed air, or water are deployed as cleaning mediums. The robust, power plant-compatible construction features a modular design for different soot blower types, reducing spare parts inventory. The blowers are equipped with cast valves for enhanced longevity and come standard with blast jet offsets to protect heating surfaces. Specific models include the LSB22 for temperatures up to 1000°C, SB22 for non-corrosive gases up to 700°C, PB22 for targeted cleaning, TB22 for economizers and SCR systems, and DB22 for heat exchangers with lighter contaminants.
The screw blower is best suited for areas with a flue gas temperature of up to 450 °C (700 °C for non-corrosive flue gases). The blowpipe of the screw blower remains partially in the flue gas path and is stored there. This results in the advantage of a shorter extension length with usually 4 high-performance nozzles. The SB22 is used for travel distances of up to 6 meters
Data on SB22:
- Type screw blower
- Application range Up to approx. 450°C flue gas temperature (700°C for non-corrosive flue gases)
- Travel distance up to 6m
- Feature Shorter removal length, blowpipe remains partially in the boiler
