Rising - Model 304L -Stainless Steel Pipe
The SS 304L is an austenitic low-carbon stainless steel grade. A 304L Stainless Steel Pipe is produced with a chemical content of 18% chromium and 8% nickel. These pipes are resistant to carbon precipitation and have enhanced corrosion resistance properties. The Stainless Steel 304L Pipe works well in harsh conditions and in high and cryogenic temperatures. The non-magnetic grade can be easily annealed and can be readily cold worked.
A SS 304L Pipe has good strength and possesses a minimum tensile strength of 485mpa with minimum proof stress of 170mpa. The pipes have a hardness of 201 HB and can be elongated by 40% in the system. The 304L Stainless Steel Tubing has higher strength in comparison to a pipe. These tubes can be both hot and cold rolled and showcase enhanced durability. They are easy to bend and coil without causing any fracture or wrinkling. Stainless Steel 304L Tubes have a density of 7.90 g/cm3 and possess a melting range between 1398 to 1421 degrees C. These tubes are common in petroleum, mining, medical, food processing, power generation, and other applications. A Stainless Steel 304L Pipe Supplier can produce pipes in different sizes and schedules to suit the requirements of different industries.
What is ASTM A312 TP304L?
The ASTM A312 TP304L grade is the most used steel pipe in the world due to its unique chemistry and availability. The items cover pipes in diameters from 1/8 to 30 and can be produced in seamless, welded, and erw specifications. ASTM A312 TP304L Seamless Pipe is a high-strength grade that is produced via an extrusion process. These pipes are less prone to corrosion but have a rough extrusion process. The 304L Seamless Stainless Steel Pipe is suitable for higher pressure and temperatures. These pipes are designed in nominal sizes up to 24 inches or less. ASME SA 312 TP304L Welded Pipe is produced as metal is rolled and welded using a standard procedure. These pipes are cheaper than seamless pipes and are preferred in applications where stress on the system is low. The 304L SS ERW Pipe is longitudinally welded and possesses a consistent wall thickness.
- Specifications: ASTM A 312 ASME SA 312 / ASTM A 358 ASME SA 358
- Dimensions: ASTM, ASME and API
- SS 304L Pipes: 1/2 inch NB – 16 inch NB
- ERW 304L Pipes: 1/2 inch NB – 24 inch NB
- EFW 304L Pipes: 6 inch NB – 100 inch NB
- Size: 1/8 inch NB TO 30 inch NB IN
- Specialized in: Large Diameter Size
- Schedule: SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
- Type: Seamless / ERW / Welded / Fabricated / LSAW Pipes
- Form: Round, Square, Rectangular, Hydraulic Etc
- Length: Single Random, Double Random & Cut Length.
- End: Plain End, Beveled End, Treaded
