Liquiflo - Model 33F - Standard Duty Gear Pump

SHARE
Liquiflo's H-Series Gear Pumps are a modern iteration of the older 3-Series, adeptly catering to new applications while providing an optimal upgrade path for existing setups. These gear pumps, constructed using high-grade materials such as 316 Stainless Steel, Alloy-C, and Alloy-20, offer flexibility with both Sealed and Mag-drive configurations. With flow rates reaching up to 55 gallons per minute and capable of handling differential pressures up to 100 PSI, they are well-suited for demanding industrial environments. Key to their design is the versatility in connection options, such as threaded and flanged ports, allowing integration into diverse systems. Their robust construction ensures reliability across various operational conditions, making them a preferred choice in advanced fluid handling solutions. The transition from 3-Series to H-Series involves adopting these modern features for enhanced performance and longevity.
Most popular related searches
gear pump
fluid handling system
coupling sealing
fluid handling

The 3-Series Gear Pumps have been replaced by the H-Series gear pump line. The H-Series is recommended for all new applications as well as an upgrade to any existing 3-Series installations.

Liquiflo's original 3-Series Gear Pumps are manufactured from 316 Stainless Steel, Alloy-C or Alloy-20 and are available in Sealed or Mag-drive configurations with flows up to 55 GPM and differential pressures up to 100 PSI.

Port Connections: 1/4" NPT/BSPT
1/2" FLG*
DIN10 PN16 FLG
Max Flow Rate: 1.45 GPM; 5.5 LPM
Max Differential Pressure: 100 PSI; 6.9 BAR
Max Discharge Pressure: 300 PSIG; 20.7 BARG
Max Viscosity: 100,000 CPS (mPas)
Max Temperature: 500 °F; 260 °C
Min Temperature: -40 °F; -40 °C
Max Speed: 1750 RPM
NPSHR @ Max Speed: 2.0 FT; 0.6 M
Lift (Dry) @ Max Speed: 1.5 FT; 0.45 M
Weight (without motor)
  Sealed, Long-Coupled
  Sealed, Close-Coupled
  Mag, Close-Coupled:
2.5 LBS; 1.1 KGS
23 LBS; 10.5 KGS
31 LBS; 14 KGS
