StormTrap - Model DoubleTrap -Oil and Water Separator
Capable of incorporating several StormTrap solutions in a small, adjustable footprint to maximize total water storage and reduce excavation and project costs
DoubleTrap utilizes depth and is available in internal heights that range from 2’-2” to 15’-0”. By going deeper as opposed to wider to fulfill total water storage requirements, DoubleTrap can minimize the overall project footprint and reduce total excavation and project costs. The DoubleTrap product pairs with a range of stormwater applications to create an effectual stormwater quality solution that exceeds ordinances and requirements.
Precast pieces make for a quick and efficient installation that provides a high-strength, long-lasting solution. The height of the DoubleTrap does not compromise the strength of the precast concrete modules and can be specified to withstand extreme loading requirements. DoubleTrap is easily maintained, innovative and cost-effective.
The DoubleTrap product works seamlessly with detention applications, and by including precast openings in the base units, DoubleTrap promotes infiltration and groundwater recharge. The product can also integrate treatment and rainwater harvesting options in addition to functioning as part of a treatment train for an enhanced water quality solution.
Robust Construction
- Made of reinforced, high-strength precast concrete available in internal heights that range from 2′-2″ to 15′-0″
- Designed to exceed HS-20 loading with minimum 6″ cover
- Options for extreme loading situations such as high-cover applications, Cooper E-80 and aircraft loading
Efficient Design
- Flexible, modular design easily accommodates existing utilities, light pole foundations, trees and other job site constraints
- Maximizes storage volume while minimizing project footprint and cost
- Precast base openings promote infiltration and groundwater recharge
Quick Installation
- Modular construction facilitates a quick and efficient installation, reducing excavation and labor costs
- Meets stormwater local regulations without compromising land use
Easy Maintenance
- Total void storage allows for a fully accessible and maintainable system
- Watertight applications available
